Steel Parallel
Next > >
Steel Parallel
Product Code : 20
Product Description
Having achieved a distinct niche with our five decades of colossal industry experience, we come up with precision engineered Steel Parallel. Available in variegated dimensions, patterns and specifications; our product is widely utilized for straightening and parallelism applications. To meet with the various demands of our customers, we supply this in bulks following their requirements. Steel Parallel, we offer is well-acclaimed by our clients both in the domestic as well as overseas market for the below enlisted attributes:
- High hardness & toughness
- Compact design
- Accurate readout
- Optimum performance
- Fine finish
Other info:
Standard sizes and accuracy of Luthra Steel Parallel As per IS-4241:1967, Grade 1
| Sizes L X B X H mm | Accuracy Microns um | |
| Straightness | Parallelism | |
| 100 x 10 x 5 | +/- 1.25 | +/- 1.25 |
| 150 x 50 x 25 | +/- 2.5 | +/- 2.5 |
| 150 x 80 x 40 | +/- 2.5 | +/- 2.5 |
| 200 x 35 x 20 | +/- 4.0 | +/- 4.0 |
| 250 x 45 x 25 | +/- 4.0 | +/- 4.0 |
| 250 x 60 x 30 | +/- 4.0 | +/- 4.0 |
| 300 x 60 x 30 | +/- 5.0 | +/- 5.0 |
|
